Midea 1.5 Ton 3 Star Fixed Speed Split AC – SANTIS MAX CLS (MAS18SM3R36F0)

PRODUCT DETAILS

Brand: Midea
Product Type: Fixed Speed Split Air Conditioner
Capacity: 1.5 Ton
Model: MAS18SM3R36F0
Series: SANTIS MAX CLS
Star Rating: 3 Star
Refrigerant: R32
Rated Power Supply: 230 V, 1 Phase, 50 Hz
Maximum Cooling Capacity: 5760 W
Rated Cooling Capacity: 5050 W
Half Load Cooling Capacity: 2525 W
Rated Power Input: 1480 W
Half Load Power Input: 525 W
ISEER: 4.40 W/W
Annual Power Consumption: 887.80 kWh
Rated Current: 6.5 A
Air Flow Rate: 580 CFM
Indoor Noise Level: 42 / 40 / 37 dB
Colour: White

WARRANTY:
• 5 Years Comprehensive Product Warranty
• 10 Years Warranty on Compressor

KEY FEATURES:
• 1.5 Ton Capacity
• 3 Star Energy Rating
• Fixed Speed Technology
• R32 Refrigerant
• 4-in-1 Gear Control
• Insta Cool / Super Turbo
• PM2.5 Filter
• HD Filter
• Refrigerant Leakage Detector
• Prime Guard / Blue Fin Coating
• Auto Cleaner
• Follow Me
• Auto Restart
• Sleep Mode
• Auto Swing
• Dry Mode
• Security Lock
• Hidden Display
• Stabilizer-Free Operation
• High Ambient Cooling up to 52°C

ABOUT THIS ITEM:
• 1.5 Ton Capacity: Suitable for cooling medium-sized rooms and spaces.
• Fixed Speed Technology: Provides consistent cooling performance for everyday use.
• 4-in-1 Gear Control: Allows cooling performance and power consumption to be adjusted according to requirements.
• Insta Cool / Super Turbo: Provides rapid cooling for quicker comfort.
• PM2.5 Filter: Helps filter fine dust particles and airborne pollutants from the air.
• Refrigerant Leakage Detector: Detects refrigerant leakage and provides an alert.
• Prime Guard / Blue Fin Coating: Helps protect the heat exchanger against corrosion.
• Auto Cleaner: Helps maintain a cleaner indoor unit by reducing moisture accumulation.
• Follow Me: Uses the temperature around the remote control to help regulate cooling.
• High Ambient Cooling: Designed to operate effectively in ambient temperatures up to 52°C.
• Stabilizer-Free Operation: Designed to operate within the specified voltage range without requiring a separate stabilizer.

COOLING & PERFORMANCE SPECIFICATIONS:
• Capacity: 1.5 Ton
• Maximum Cooling Capacity: 5760 W
• Rated Cooling Capacity: 5050 W
• Half Load Cooling Capacity: 2525 W
• Rated Power Input: 1480 W
• Half Load Power Input: 525 W
• Star Rating: 3 Star
• ISEER: 4.40 W/W
• Annual Power Consumption: 887.80 kWh
• Air Flow Rate: 580 CFM
• Indoor Noise Level: 42 / 40 / 37 dB
• Rated Voltage: 230 V
• Rated Frequency: 50 Hz
• Rated Current: 6.5 A

FILTERS & AIR QUALITY:
• HD Filter
• PM2.5 Filter
• Refrigerant Leakage Detector
• Auto Cleaner

CONVENIENCE & SAFETY FEATURES:
• Auto Restart
• Auto On/Off Timer
• Sleep Mode
• Follow Me
• Auto Fan Speed
• Auto Swing
• Dry Mode
• Security Lock
• Hidden Display
• Intelligent CRF Alert
• Stabilizer-Free Operation
• Louver Position Memory
• Double Drain

DESIGN & ADDITIONAL FEATURES:
• Body Colour: White
• Installation Type: Wall Mounted
• Condenser: Copper
• Condenser Protection: Blue Fin Coating

PRODUCT DIMENSIONS & WEIGHT:
• Indoor Unit Dimensions (L × B × H): 104.5 × 23.5 × 31.5 cm
• Outdoor Unit Dimensions (L × B × H): 84.5 × 31 × 70 cm
• Indoor Unit Weight: 10.1 kg
• Outdoor Unit Weight: 25.5 kg

IN THE BOX:
• Indoor Unit
• Outdoor Unit
• Connecting Kit Pipe
• Remote Control
• User Manual
• Warranty Card

INSTALLATION:
• Installation should be carried out by an authorized Midea service technician.
• Ensure proper electrical connection and earthing before installation.
• The indoor and outdoor units should be installed on suitable, stable surfaces.
• Ensure proper refrigerant piping, drainage and electrical connections during installation.
